Helicopter Rotor Balancing
Vibrex 2000 and Vibrex 2000 Plus User Guide 95
After the Vibrex unit has taken balance measurements, the following
screen displays:
From this screen, the user has the following options:
•Press
ANNOTATE
to store and annotation with the current
measurements.
•Press
REDO MEAS
to retake the current measurements.
•Press
GO BACK to cancel and erase the current measurements.
•Press
START to save the current measurements and continue with
the program.
5. Plot the readings on the appropriate chart at the intersection of clock
angle and IPS. Follow the fine lines perpendicular to the heavy
borders of the chart.
6. Read the changes specified on the heavy border and apply these
changes to the rotor system.
7. When the user is finished, press the
GO BACK key as many times as
necessary to return to the Main Menu screen.
ANNOTATE MEAS 3
save with START
WHAT DO YOU WANT TO
DO WITH MEAS 3 ?
REDO MEAS 3
cancel with GO BACK
