80 Chadwick-Helmuth Company, Inc.
Chapter 5 - General Operation
Read the Balance Quality graph, as follows:
• Anything better than or equal to acceptable means the propeller
meets the balance guidelines given in The Smooth Propeller.
• The label unacceptable means the balance reading is higher than
the recommended 0.2 IPS.
• The label warning indicates the propeller has a balance reading
over 1.2 IPS. The user must investigate the reason for an IPS reading
higher than 1.2 IPS before trying to balance the propeller.
The following table shows the values the Vibrex unit has assigned to the
text labels in the Prop Balance Quality screen:
There are two additional context keys for use during the balance
operation, as follows:
DONE
Press when the balance level is at the
desired point and there is no need to
make any more changes.
INSTALL PERMANENTLY
Press if the user needs to move the
weight inside the spinner. Pressing this
key accesses the Split Weights and
Radius Change menus.
Label IPS Reading
Best Less than 0.05
Very good 0.05 to 0.09
Good 0.10 to 0.14
Acceptable 0.15 to 0.19
Unacceptable 0.20 to 1.19
Warning Greater than 1.20
