Appendix B Default Patterns List
B-49
The pattern for left eye is a white screen
with black text.
The pattern for right eye is a black
screen with white text.
When a 3D image is composed, it can
inspect if the left and right eye shaded
switching of 3D glasses is correct. The
text “LEFT” and “RIGHT” provide a quick
inspection to check if the left/right eye
images are existed. The left and right
patterns in black and white with Chroma
3D optical measurement equipment can
meet the automatic 3D crosstalk
measurement function.
The pattern for left eye is a black screen
with white text.
The pattern for right eye is a white
screen with black text.
When a 3D image is composed, it can
inspect if the left and right eye shaded
switching of 3D glasses is correct. The
text “LEFT” and “RIGHT” provide a
quick inspection to check if the left/right
eye images are existed. The left and
right patterns in black and white with
Chroma 3D optical measurement
equipment can meet the automatic 3D
crosstalk measurement function.
The pattern for left eye is black for the left
half and white for the right half. It is a
reversed pattern for right eye.
The pattern for right eye is white for the
left half and black for the right half. It is a
reversed pattern for left eye.
