The following figure shows the wall mount kit installed on the phone.
Figure 25: Back View of ADA Non-Lockable Wall Mount Kit Installed on Phone with Key Expansion Module
The following figure shows the phone with the wall mount kit from the side.
Figure 26: Side View of ADA Non-Lockable Wall Mount Kit Installed on Phone with Key Expansion Module
Cisco Unified IP Phone 8961, 9951, and 9971 Administration Guide for Cisco Unified Communications Manager 10.0
(SIP)
335
Cisco Unified IP Phone Non-Lockable Wall Mount
ADA Non-Lockable Wall Mount Kit for 8961 Series and 9900 Series IP Phones with Key Expansion Module
REVIEW DRAFT - CISCO CONFIDENTIAL
