Cisco ASR 1013 Hardware Installation Guide

SUMMARY STEPS
1.
Use the wire stripper to strip one end of the AWG #6 wire approximately 0.75 inches (19.05 mm).
2.
Insert the AWG #6 wire into the wire receptacle on the grounding lug.
3.
Use the crimping tool to carefully crimp the wire receptacle around the wire; this step is required to ensure
a proper mechanical connection.
4.
Attach the grounding lug with the wire so that the grounding wire does not overlap the power supply.
5.
Locate the chassis ground connector on the bottom rear of the Cisco ASR 1013 chassis.
6.
Insert the two screws through the holes in the grounding lug as shown in Figure 186: Attaching the Cisco
ASR 1013 Router Ground Connection, on page 390.
7.
Use the Number 2 Phillips screwdriver to carefully tighten the screws until the grounding lug is held firmly
to the chassis. Do not overtighten the screws.
8.
Connect the opposite end of the grounding wire to the appropriate grounding point at your site to ensure
an adequate chassis ground.
DETAILED STEPS
Step 1
Use the wire stripper to strip one end of the AWG #6 wire approximately 0.75 inches (19.05 mm).
Step 2
Insert the AWG #6 wire into the wire receptacle on the grounding lug.
Step 3
Use the crimping tool to carefully crimp the wire receptacle around the wire; this step is required to ensure a proper
mechanical connection.
Step 4
Attach the grounding lug with the wire so that the grounding wire does not overlap the power supply.
Step 5
Locate the chassis ground connector on the bottom rear of the Cisco ASR 1013 chassis.
Cisco ASR 1000 Series Router Hardware Installation Guide
389
Cisco ASR 1013 Router Overview and Installation
Recommended Tools and Supplies
