Chapter 18 Configuring Voice VLAN
Configuring Voice VLAN
• Configuring the IP Phone to Trust the CoS Priority of Incoming Data Frames, page 18-6
Configuring Ports to Carry Voice Traffic in IEEE 802.1Q Frames
Beginning in privileged EXEC mode, follow these steps to configure a port to carry voice traffic in IEEE
802.1Q frames for a specific VLAN:
To remove voice VLAN, use the no switchport voice vlan interface configuration command or the
switchport voice vlan none interface configuration command.
Configuring Ports to Carry Voice Traffic in IEEE 802.1p Priority-Tagged Frames
Beginning in privileged EXEC mode, follow these steps to configure a port to instruct the IP phone to
give voice traffic a higher priority and to forward all traffic through the native VLAN.
To return the port to its default setting, use the no switchport voice vlan interface configuration
command.
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
interface interface-id Specify the interface connected to the IP phone, and enter interface
configuration mode.
Step 3
switchport voice vlan vlan-id Instruct the Cisco IP Phone to forward all voice traffic through the specified
VLAN. By default, the Cisco IP Phone forwards the voice traffic with
an IEEE 802.1Q priority of 5.
Valid VLAN IDs are from 1 to 4094.
Step 4
end Return to privileged EXEC mode.
Step 5
show interfaces interface-id
switchport
Verify your voice VLAN entries.
Step 6
copy running-config startup-config (Optional) Save your entries in the configuration file.
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
interface interface-id Specify the interface connected to the IP phone, and enter interface
configuration mode.
Step 3
switchport voice vlan dot1p Instruct the switch port to use IEEE 802.1p priority tagging for voice traffic
and to use the default native VLAN (VLAN 0) to carry all traffic. By default,
the Cisco IP phone forwards the voice traffic with an IEEE 802.1p priority
of 5.
Step 4
end Return to privileged EXEC mode.
Step 5
show interfaces interface-id
switchport
Verify your voice VLAN entries.
Step 6
copy running-config startup-config (Optional) Save your entries in the configuration file.

Cisco Catalyst 2950 Specifications

General

Forwarding Bandwidth	8.8 Gbps
Switching Capacity	13.6 Gbps
Forwarding Rate	6.6 Mpps
Weight	3.6 kg
RAM	16 MB
Flash Memory	8 MB
Operating Humidity	10% to 85% non-condensing
Uplink Ports	2 x 10/100/1000Base-T
Dimensions	4.4 cm x 44.5 cm x 24.2 cm
Remote Management Protocol	SNMP, Telnet, HTTP
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p
Status Indicators	system
Operating Temperature	0 to 45°C
Ports	24 x 10/100 Ethernet ports
MAC Address Table Size	8, 192 entries
Power Supply	Internal 100-240V AC, 50-60Hz
