Chapter 30 Configuring EtherChannels
Configuring EtherChannels
• An EtherChannel supports the same allowed range of VLANs on all the interfaces in a trunking
Layer 2 EtherChannel. When configuring an interface for PAgP, if the allowed range of VLANs is
not the same, the interfaces do not form an EtherChannel even when PAgP is set to the auto or
desirable mode. When configuring an interface for LACP, if the allowed range of VLANs is not the
same, the interfaces do not form an EtherChannel even when LACP is set to the active or passive
mode.
• Interfaces with different spanning-tree path costs can form an EtherChannel if they are otherwise
compatibly configured. Setting different spanning-tree path costs does not, by itself, make interfaces
incompatible for the formation of an EtherChannel.
• Configure only PAgP-type EtherChannels on Catalyst 2950 Long-Reach Ethernet (LRE) switch
ports.
Configuring Layer 2 EtherChannels
You configure Layer 2 EtherChannels by configuring the Ethernet interfaces with the channel-group
interface configuration command, which creates the port-channel logical interface. You cannot put a
Layer 2 interface into a manually created port-channel interface.
Note Layer 2 interfaces must be connected and functioning for the software to create port-channel interfaces.
Beginning in privileged EXEC mode, follow these steps to assign a Layer 2 Ethernet interface to a
Layer 2 EtherChannel:
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
interface interface-id Specify a physical interface to configure, and enter interface
configuration mode.
Valid interfaces include physical interfaces.
Up to eight interfaces of the same type and speed can be
configured for the same group.
Step 3
switchport mode {access | trunk}
switchport access vlan vlan-id
Assign all interfaces as static-access ports in the same VLAN, or
configure them as trunks.
If you configure the interface as a static-access port, assign it to
only one VLAN. The range is 1 to 4094.

Cisco Catalyst 2950 Specifications

General

Forwarding Bandwidth	8.8 Gbps
Switching Capacity	13.6 Gbps
Forwarding Rate	6.6 Mpps
Weight	3.6 kg
RAM	16 MB
Flash Memory	8 MB
Operating Humidity	10% to 85% non-condensing
Uplink Ports	2 x 10/100/1000Base-T
Dimensions	4.4 cm x 44.5 cm x 24.2 cm
Remote Management Protocol	SNMP, Telnet, HTTP
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p
Status Indicators	system
Operating Temperature	0 to 45°C
Ports	24 x 10/100 Ethernet ports
MAC Address Table Size	8, 192 entries
Power Supply	Internal 100-240V AC, 50-60Hz
