20-15
Catalyst 2950 and Catalyst 2955 Switch Software Configuration Guide
78-11380-12
Chapter 20 Configuring IGMP Snooping and MVR
Displaying IGMP Snooping Information
This example shows how to set the IGMP snooping querier source address to 10.0.0.64 and to verify the
configuration:
Switch# configure terminal
Switch(config)# ip igmp snooping querier 10.0.0.64
Switch(config)# end
This example shows how to set the IGMP snooping querier maximum response time to 25 seconds and
to verify the configuration:
Switch# configure terminal
Switch(config)# ip igmp snooping querier query-interval 25
Switch(config)# end
This example shows how to set the IGMP snooping querier timeout to 60 seconds and to verify the
configuration:
Switch# configure terminal
Switch(config)# ip igmp snooping querier timeout expiry 60
Switch(config)# end
This example shows how to set the IGMP snooping querier feature to version 2 and to verify the
configuration:
Switch# configure terminal
Switch(config)# no ip igmp snooping querier version 2
Switch(config)# end
Displaying IGMP Snooping Information
You can display IGMP snooping information for dynamically learned and statically configured router
ports and VLAN interfaces. You can also display MAC address multicast entries for a VLAN configured
for IGMP snooping.
To display IGMP snooping information, use one or more of the privileged EXEC commands in
Table 20-4. For more information about the keywords and options in these commands, see the command
reference for this release. For examples of output from the commands in Table 20-4, see the command
reference for this release.
Step 9
show ip igmp snooping vlan vlan-id (Optional) Verify that the IGMP snooping querier is enabled on the
VLAN interface.
Step 10
copy running-config startup-config (Optional) Save your entries in the configuration file.
Command Purpose
Table 20-4 Commands for Displaying IGMP Snooping Information
Command Purpose
show ip igmp snooping [vlan vlan-id] Display the snooping configuration information for all VLANs on the
switch or for a specified VLAN.
(Optional) Enter vlan vlan-id to display information for a single VLAN.
show ip igmp snooping group [vlan vlan-id] Display information about the IGMP multicast groups, the compatibility
mode, and the ports that are associated with each group.
(Optional) Enter vlan vlan-id to display information for a single VLAN.

Cisco Catalyst 2950 Specifications

General

Forwarding Bandwidth	8.8 Gbps
Switching Capacity	13.6 Gbps
Forwarding Rate	6.6 Mpps
Weight	3.6 kg
RAM	16 MB
Flash Memory	8 MB
Operating Humidity	10% to 85% non-condensing
Uplink Ports	2 x 10/100/1000Base-T
Dimensions	4.4 cm x 44.5 cm x 24.2 cm
Remote Management Protocol	SNMP, Telnet, HTTP
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p
Status Indicators	system
Operating Temperature	0 to 45°C
Ports	24 x 10/100 Ethernet ports
MAC Address Table Size	8, 192 entries
Power Supply	Internal 100-240V AC, 50-60Hz
