27-8
Catalyst 2950 and Catalyst 2955 Switch Software Configuration Guide
78-11380-12
Chapter 27 Configuring SNMP
Configuring SNMP
Configuring Community Strings
You use the SNMP community string to define the relationship between the SNMP manager and the
agent. The community string acts like a password to permit access to the agent on the switch. Optionally,
you can specify one or more of these characteristics associated with the string:
• An access list of IP addresses of the SNMP managers that are permitted to use the community string
to gain access to the agent
• A MIB view, which defines the subset of all MIB objects accessible to the given community
• Read and write or read-only permission for the MIB objects accessible to the community
Beginning in privileged EXEC mode, follow these steps to configure a community string on the switch:
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
snmp-server community string [view
view-name] [ro | rw] [access-list-number]
Configure the community string.
• For string, specify a string that acts like a password and permits
access to the SNMP protocol. You can configure one or more
community strings of any length.
• (Optional) For view, specify the view record accessible to the
community.
• (Optional) Specify either read-only (ro) if you want authorized
management stations to retrieve MIB objects, or specify
read-write (rw) if you want authorized management stations to
retrieve and modify MIB objects. By default, the community
string permits read-only access to all objects.
• (Optional) For access-list-number, enter an IP standard access list
numbered from 1 to 99 and 1300 to 1999.
Step 3
access-list access-list-number {deny |
permit} source [source-wildcard]
(Optional) If you specified an IP standard access list number in Step
2, then create the list, repeating the command as many times as
necessary.
• For access-list-number, enter the access list number specified in
Step 2.
• The deny keyword denies access if the conditions are matched.
The permit keyword permits access if the conditions are
matched.
• For source, enter the IP address of the SNMP managers that are
permitted to use the community string to gain access to the agent.
• (Optional) For source-wildcard, enter the wildcard bits in dotted
decimal notation to be applied to the source. Place ones in the bit
positions that you want to ignore.
Recall that the access list is always terminated by an implicit deny
statement for everything.
Step 4
end Return to privileged EXEC mode.
Step 5
show running-config Verify your entries.
Step 6
copy running-config startup-config (Optional) Save your entries in the configuration file.
