Cisco Catalyst 2950 User Manual

30-13
Catalyst 2950 and Catalyst 2955 Switch Software Configuration Guide
78-11380-12
Chapter 30 Configuring EtherChannels
Configuring EtherChannels
Configuring Hot Standby Ports
When enabled, LACP tries to configure the maximum number of LACP-compatible ports in a channel,
up to a maximum of 16 ports. Only eight LACP links can be active at one time. Any additional links are
put in a hot standby state. If one of the active links becomes inactive, a link that is in hot standby mode
becomes active in its place.
If more than eight links are configured for an EtherChannel group, the software determines which of the
hot standby ports to make active based on:
• LACP port-priority
• Port ID
All ports default to the same port priority. You can change the port priority of LACP EtherChannel ports
to specify which hot standby links become active first by using the lacp port-priority interface
configuration command to set the port priority to a value lower than the default of 32768.
The hot standby ports that have lower port numbers become active in the channel first unless the port
priority is configured to be a lower number than the default value of 32768.
Note If LACP is not able to aggregate all the ports that are compatible (for example, the remote system might
have more restrictive hardware limitations), all the ports that cannot be actively included in the
EtherChannel are put in hot standby state and are used only if one of the channeled ports fails.
Configuring the LACP System Priority
You can set the system priority for all the EtherChannels that are configured for LACP by using the
lacp system-priority privileged EXEC command. The range is from 1 to 65535.
Note The lacp system-priority command is global. You cannot set a system priority for each
LACP-configured channel separately.
We recommend using this command only when there are a combination of LACP-configured
EtherChannels that are in both active and standby modes.
Step 5
show running-config
or
show lacp channel-group-number
internal
Verify your entries.
Step 6
copy running-config startup-config (Optional) Save your entries in the configuration file.
Command Purpose

Cisco Catalyst 2950 Specifications

General

Forwarding Bandwidth	8.8 Gbps
Switching Capacity	13.6 Gbps
Forwarding Rate	6.6 Mpps
Weight	3.6 kg
RAM	16 MB
Flash Memory	8 MB
Operating Humidity	10% to 85% non-condensing
Uplink Ports	2 x 10/100/1000Base-T
Dimensions	4.4 cm x 44.5 cm x 24.2 cm
Remote Management Protocol	SNMP, Telnet, HTTP
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p
Status Indicators	system
Operating Temperature	0 to 45°C
Ports	24 x 10/100 Ethernet ports
MAC Address Table Size	8, 192 entries
Power Supply	Internal 100-240V AC, 50-60Hz
