Cisco RV345 Administration Guide

The switch uses the incoming packet priority 'CoS; bits and classifies the packet to user
configured queue.
•
Based on the CoS value of the incoming packet, map the traffic to the different
queues by selecting the queues from the drop-down list.
CoS-based
Step 2
Click Apply.
Switch Queuing
In Switch Queuing, the queue weight for all the four queues per port can be configured by assigning weights
to each queue. The range of weights can be from 1 to 100. When LAG is enabled, the user can define the
queue weights for all four queues.
If the weight is 0, this means that the queue is in highest priority queue.Note
To configure LAN Port Queue Weight, click QoS > Switch Queuing and complete the following steps:
Step 1
In LAN Port Queue Weight, select the appropriate weight for each of the queues.
Step 2
Click Apply.
Step 3
Click Restore Defaults to restore system default settings.
Step 4
In the LAG Port Queue Weight table, the LAG ports and their queue weights are displayed.
RV345/345P Administration Guide
51
QoS
Switch Queuing

Cisco RV345 Specifications

General

WAN Ports	2
LAN Ports	16
Max VPN Tunnels	50
Firewall Throughput	900 Mbps
RAM	512 MB
Flash Memory	256 MB
Gigabit Ethernet Ports	18
Firewall Protection	Yes
VPN Support	Yes
Wireless	No
Device Type	Router
Encryption	AES, 3DES
Operating Temperature	0 to 40 °C
Storage Temperature	-20 to 70°C (-4 to 158°F)
Humidity	10% to 85% noncondensing
USB Ports	2
Ports	18 x RJ-45
