Check to enable to symmetric flow control. Flow control is used to send pause frames
and respecting pause frames to and from the LAN PC connected to the device.
Flow Control
Select the port setting mode from the drop-down list.Mode
Step 3
In the Port Mirror Configuration section, enter the following information:
Check Enable to enable port mirror configuration.Enable
Select anyone of the LANs (LAN1 to LAN16) from the drop-down list.
Destination Port
The port to monitor the traffic sending for mirroring.
Select anyone of the LANs (LAN1 to LAN16) from the drop-down list.
Monitored Port
Step 4
In the Link Aggregation Configuration Table, enter the following information:
Lists the name of the link group.Group Name
Select to remove the port from the LAG group.
Select anyone of the LANs (LAN1 to LAN16) from the drop-down list.
Unassigned
Select to apply link aggregation on appropriate port for traffic.
Select anyone of the LANs (LAN1 to LAN16) from the drop-down list.
LAG1
All the existing configurations on the ports (which are going to be part of LAG) are
lost.
Warning
Step 5
Click Apply.
PoE Settings (RV345P)
Power over Ethernet (PoE) is a technology for LANs (local area networks) that allows a device to be operated
by electrical current which is transported by data cables rather than by electrical wires.
For PoE to work, the electrical current must pass thru the data cable at the power-supply end, and come out
at the device end, in such a way that the current is kept separate from the data signal so that neither interferes
with the other. The current enters the cable by means an injector. If the device at the other end of the cable is
PoE compatible, then that device will function properly without modification. If the device is not PoE
compatible, then a picker must be installed to remove the current from the cable.
RV345/345P Administration Guide
54
