Form No. 56043161 - Clean Track

L24 - 11

Batteries and Chargers

Attention: See the Electrical System section for battery installation, battery maintenance and charger

system requirements.

Lubricating the Machine

Lubricate the following components:

Refer to Figure 1.

• Once a month lubricate the General

Pivot Points for the Brush Linkage

(A). For best results, use a silicone

spray.

• Once per quarter, grease the Rear

Caster Wheel Swivel (B). Wipe off

any excess grease to avoid staining

carpet.

Figure 1

Front
