Form No. 56043161 - Clean Track

L24 - 69

Speed Control Programming Options

FollowingisalistofthespeedcontrolparametersthatcanbeadjustedusingaCurtishandheldprogrammers:

• M1 MAX SPEED – Transport/Scrub speed maximum limit (% of full throttle)

• M2 MAX SPEED – Not applicable

• M1 MIN SPEED – Transport/Scrub speed maximum limit with the speed limit pot in minimum position (% of full

throttle limited by speed limit pot)

• M2 MIN SPEED – Not applicable

• M1 REVERSE MAX SPEED – Reverse Transport/Scrub speed maximum limit (% of full throttle)

• M2 REVERSE MAX SPEED – Not applicable

• REVERSE MIN SPEED – Transport/Scrub speed maximum limit with the speed limit pot in minimum position (% of

full throttle limited by speed limit pot)

• THROTTLE AUTOCAL – Used for calibration of the throttle assembly

Installation Checkout for the Curtis Speed Controller

Warning!

The1210controllerisinherentlyahigh-powerdevice.Whenworkingaroundanybatterypoweredvehicle,appropriate

safetyprecautionsshouldbetaken.Theseinclude,butarenotlimitedto:

• Propertraining,

• Wearingeyeprotection,

• Avoidinglooseclothingandjewelry,and,

• Using insulated wrenches.

Afterinstallingacontrollerandbeforeoperatingthevehicle,carefullycompletethefollowingcheckoutprocedure.Ifyou

ndaproblemduringthecheckout,refertotheDiagnostics section of this chapter for further information.

The installation checkout can be conducted with or without the handheld programmer. The checkout procedure is

easierwithaprogrammer.Otherwise,observetheStatusLEDforcodes(locatedonoperatorpanelwandindicator

light). The part number of the handheld programmer is 56409441.

Warning!

• Put the vehicle up on blocks to get the drive wheel off the ground before beginning these tests.

• Turn the Key Switch off and make sure the throttle is in neutral.

• Donotstand,orallowanyoneelsetostanddirectlyinfrontoforbehindthevehicleduringthetests.

1. Removeelectricalpaneltoaccesscontroller,thenobserveLEDstatuslightontouchpadoperatorpanelwand

indicatorlight.Ifaprogrammerisavailable,connectittotheprogrammerplug-inport.

2. TurntheKeySwitchon.Theprogrammershould“powerup”withaninitialdisplay.Ifneitherhappens,checkfor

continuity in the Key Switch circuit and controller ground.

3. Ifyouareusingaprogrammer,putitintothediagnosticmodebypressingtheDIAGNOSTICS key. The display

should indicate No Faults Found.
