76 - Form No. 56043161 - Clean Track

L24

To Switch the On-board Chemical Mixing System On and Off

The Detergent System switch (B) controls the chemical (detergent) pump in the Service Test Mode.

• Pressing the Detergent System switch switches on the chemical pump. The display will read CPUMP:ON.

• Pressing the Detergent System switch a second time switches off the chemical pump. The display will read

CPUMP:OFF.

Indicator Function

CPUMP:OFF The chemical pump is off.

CPUMP:ON The chemical pump is on.

Main Control Programming Options

Selecting the Low Voltage Cutout Threshold

Factory Default: 20.6V (1.72 Volts/Cell)

The Clean Track

L24isequippedwithalow-voltagecutoutfeaturetopreventover-dischargingthebatteries.This

feature will automatically shut down the scrub system when the battery voltage falls to the selected threshold. The

cutoutlevelisadjustable.Thefactorydefaultsettingis20.6volts(1.72voltspercell)andthealternatesettingis21.8

volts(1.81voltspercell).Selectthecorrectcutoutlevelbasedonthebatterymanufacturer’sspecications.Itis

important to note that some maintenance-free batteries (including some gelled electrolyte cells) are capable of being

safely discharged down to 1.72 volts per cell. To select between the two cutout levels:

1. Turn the Key Switch (A) to the off position.

2. Press and hold the Scrub OFF Switch (H).

3. WhileholdingtheScrubOFFSwitch,turntheKeySwitchtotheonposition.

4. Continue to hold the Scrub OFF Switch until the scrub off indicator turns red.

5. Release the Scrub OFF Switch. The display will now show a battery icon and “20.6” or “21.8”.

6. Press and release the Scrub ON Switch (J) to select between the two options.

• Forthedefaultcutoutlevel,select“20.6”.

• Forthealternatecutoutlevel,select“21.8”.

7. Tosavethenewsetting,presstheScrubOFFSwitch.Thedisplaywillnowshowakeyicontoindicatethe

procedure is done.

8. Turn the Key Switch to the off position. The new setting will be saved and will remain in effect until it is changed

again.

Selecting the Scrub Pressure Current Limits

The Clean Track

L24 uses the combined scrub brush motor current draw to determine if the scrub pressure is correct

for the selected extract mode.

• Ifthecurrentdrawgoesabovetheupperlimit,thescrubdeckliftactuatorraisesthedeckuntilthescrubmotor

current draw is within the selected range.

• Ifthecurrentdrawgoesbelowthelowerlimit,thescrubdeckliftactuatorlowersthedeckuntilthescrubmotor

current draw is again within the selected range.
