Form No. 56043161 - Clean Track
®
L24 - 19
Control Panel Indicators
Chemical Mixing System Indicator (D1)
The machine has a Chemical Mixing System Indicator in the lower left corner of the display. When the detergent
(chemical) system is enabled, the indicator will show a detergent bottle icon. When the detergent system is disabled,
the detergent bottle icon will have a cross through it. If the operator chooses a specic mix ratio on the detergent bottle,
it will be displayed in the Chemical Mixing System Ratio Indicator (D4) to the right of the Chemical Mixing System
Indicator.
Hour Meter (D2)
The Hour Meter is shown in the upper left corner of the display for ve seconds after the machine is turned on. The
Hour Meter displays the total time spent scrubbing for the life of the machine.
Battery Indicator (D2)
After ve seconds of operation, the battery condition indicator replaces the hour meter in the upper left corner of the
display. It gives a relative indication of the state of charge of the battery pack. A fully-charged battery pack will measure
above 25.1 volts with no load applied (2.09 volts per cell). The Clean Track
®
L24 is equipped with a low-voltage
cutout feature that will turn the scrub system off when the batteries are discharged to their minimum level. There are
two different cutout levels to accommodate different battery types. See the Electrical/Main Control Programming
Options section for details. The voltage levels for the various indications are as follows (the voltages shown represent
the voltage under load):
Indicator Voltage Levels For Standard Cutout Level:
• 5 Bars = full charge down to 23.8 volts
• 4 Bars = 23.7 volts down to 23.6 volts
• 3 Bars = 23.5 volts down to 23.2 volts
• 2 Bars = 23.1 volts down to 22.5 volts
• 1 Bar = 22.4 volts down to 21.7 volts
• 0 Bars = 21.6 volts down to 20.6 volts
• Low Voltage Warning Screen = less than 20.5 volts. The scrub system will shut down.
Indicator voltage levels for alternate cutout level:
• 5 Bars = full charge down to 23.8 volts
• 4 Bars = 23.7 volts down to 23.6 volts
• 3 Bars = 23.5 volts down to 23.3 volts
• 2 Bars = 23.2 volts down to 22.9 volts
• 1 Bar = 22.8 volts down to 22.3 volts
• 0 Bars = 22.2 volts down to 21.8 volts
• Low Voltage Warning Screen = less than 21.7 volts. The scrub system will shut down.
Note:Oncethelow-voltagecutoutlevelhasbeenreachedandtheBatteryLowIndicator(D9)isdisplayed)
thebatteriesmustbeFULLYrechargedtoresetthebatteryconditionindicator.Thescrubsystemwill
notfunctionuntiltheindicatorhasbeenreset.
