Form No. 56043161 - Clean Track
®
L24 - 9
Technical Specifications
Voltage 24 Volt
Power Source (4) 6 volt batteries (wet acid and gel cell available)
Onboard Battery Charger 24 volt, 25 amp Wet/Gel Compatible
Solution Control Precision-flow electric pump/solenoid valves
Solution Tank 20 gal. [76 L]
Recovery Tank 20 gal. [76 L]
Solution Capacity 20 gal [76 L]
Solution Pump 100 psi diaphragm demand
Restoration Mode Maintenance Mode Pre-spray Mode
Solution
System
Flow Rates
0.81 gpm [3,1 L/min] 0.26 gpm [1 L/min] 0.93 gpm [3,5 L/min]
Type Cylindrical, 24” [61 cm] scrub path
Brush Motors (2) ½ hp (375 watt), permanent magnet, 960 RPM
Brushes Dual 24” [61 cm] dual counter-rotating cylindrical, with debris hopper
Scrub System
Brush Speed 960 RPM
Vacuum Motor (2) 24 VDC, three-stage bypass
Airflow 93 cfm [44 L/sec]
Water Lift 70 in H
2
O [17,4 km/hr]
Vacuum
System
Vacuum Shoes Dual 13.5” [34 cm] dual pivoting laminar flow, 45 lb down-pressure
Drive Motor 0.4 hp (300 watt) variable forward and reverse, max speed - 3 mph [4.83 km/hr]
Drive Wheels (2) 7 in. [18 cm] dia. foam-filled, gray non-marking
Drive System
Gradeability Transport – 15.4% (8.3°) Cleaning – 12.5% (7.1°)
Transport
Maintenance
Mode
Restoration
Mode
Fast
Pre-spray Mode
Heavy
Pre-spray Mode
Machine Speed
220 ft/min
[4 km/hr]
90 ft/min
[1,6 km/hr]
50 ft/min
[0,9 km/hr]
150 ft/min
[2,7 km/hr]
100 ft/min
[1,8 km/hr]
Coverage Rate Maintenance Mode - 10,800 ft
2
/hr Restoration Mode - 6,000 ft
2
/hr
Sound Pressure Level
IEC 60335-2-72: 2002 Amend. 1:2005,
ISO 11201 – 69 dB (A)
IEC 60335-2-72: 2002 Amend. 1:2005,
ISO 3744 – 86.9 Lwa
Machine Dimensions Length – 56” [142 cm] Width – 27” [69 cm] Height – 43.5” [110 cm]
Gross Weight 810 lbs [367 kg]
On-board Chemical Mixing System
Refillable Cartridge Capacity 1.25 gal [4,75 L]
Available Dilution Rates 32:1, 50:1, 64:1, 100:1, 128:1, 150:1, 200:1, 256:1, 300:1
Low Detergent Warning Standard
