750-265 6
Accessories:
• S7910A1008 Local Keyboard Display Module
• 833-3577 System Operator Interface
• DSP3944 System Display for system Setup when 833-3577 not required.
• PM7910 Program Module - Storage module for the Falcon setup parameters, may be written to for storage or used for cloning
of replacement controls or multiple systems, Commands given from the 833-3577 System Operator Interface through the
CB Falcon.
ICP Device Mates with …
Plug # Description Manf. Part Number
J1 Flame Detection
Interface
Molex 0050841060 (Shell), 0002082004 (Pin, 14-20 AWG)
J2 PWM Combustion
Blower Interface
Molex 0039012040 (Shell), 0039000059 (Pin, 18-24 AWG)
J3 Comm. Interface OST EDZ1100/9 (SCREW)
J4 Line Voltage I/O Lumberg 3623 06 K129 (IDC, Pins 1 - 6) 3615-1 06 K129 (SCREW, Pins 1 - 6)
3623 06 K130 (IDC, Pins 7 - 12) 3615-1 06 K130 (SCREW, Pins 7 - 12)
J5 Line Voltage I/O Lumberg 3623 07 K01 (IDC) 3615-1 07 K01 (SCREW)
J6 Line Voltage I/O Lumberg 3623 08 K43 (IDC) 3615-1 04 K185 (SCREW, Pins 1- 4)
3615-1 04 K188 (SCREW, Pins 5- 8)
J7 Line Voltage I/O Lumberg 3623 07 K48 (IDC) 3615-1 07 K48 (SCREW)
J8 Low Voltage I/O Lumberg 3623 06 K127 (IDC, Pins 1 - 6) 3615-1 06 K127 (SCREW, Pins 1 - 6) )
3623 06 K128 (IDC, Pins 7 - 12) 3615-1 06 K128 (SCREW, Pins 7 - 12 )
J9 Low Voltage I/O Lumberg 3623 07 K59 (IDC) 3615-1 07 K59 (SCREW)
J10 High Voltage I/O Lumberg 3623 08 K64 (IDC) 3615-1 04 K187 (SCREW, Pins 1- 4)
3615-1 04 K186 (SCREW, Pins 5- 8)
J11 High Voltage I/O Lumberg 3623 07 K30 (IDC) 3615-1 07 K30 (SCREW)
