Milwaukee, Wisconsin
www.cleaver-brooks.com
Chapter 6
Parts
Recommended Spare Parts List Model CFC ................................. 6-1
Boiler mechanical assembly ...................................................... 6-2
Boiler mechanical assembly parts list ......................................... 6-3
Connection Sizes ...................................................................... 6-3
Gas train ................................................................................. 6-4
Gas train parts list .................................................................... 6-4
MSOV Kit ................................................................................ 6-4
Electrical Assemblies ................................................................ 6-5
Electrical Assemblies Parts List .................................................. 6-6
Control Panel ........................................................................... 6-6
Blower Fuse ............................................................................. 6-6
CFC Optional Parts List ............................................................. 6-7
Vent Connections ..................................................................... 6-7
Table 6-1. Recommended Spare Parts List Model CFC
Boiler Size
Item 500 750 1000 1500 1800 2500
Ionization Electrodes 380-1062 380-1062 380-1060 380-1060 380-1060 380-1060
Dual Electrode, Sparking 380-1061 380-1061 380-1061 380-1061 380-1061 380-1061
Dual Electrode Gasket 380-1032 380-1032 380-1032 380-1032 380-1032 380-1032
Burner Canister 380-1045 380-1045 380-1029 380-1030 380-1030 380-1074
Water Side Gaskets 853-350
Manual 750-263 750-263 750-263 750-263 750-263 750-263
Falcon Controller, Hydronic 833-3639 833-3639 833-3639 833-3639 833-3639 833-3639
Power Supply, 12VDC 832-2410 832-2410 832-2410 832-2410 832-2410 832-2410
Fuses (5A), Control Circuit 832-1811 832-1811 832-1811 832-1811 832-1811 832-1811
Gasket,Burner Canister (2) 380-1053 380-1053 380-1033 380-1034 380-1034 380-1034
Gasket, Adapter to Blower 380-1037 380-1037 380-1037 380-1076 380-1038 380-1038
Cable, Blower Signal 832-2434 832-2434 832-2434 832-2434 832-2434 832-2434
Ionization Cable (Flame Rod) 826-157 826-157 826-157 826-157 826-157 826-157
Ignition Cable (2) 826-156 826-156 826-156 826-156 826-156 826-156
Blower Power Cord 832-2101 832-2101 832-2101 832-2101 832-2101 832-2101
Blower Fuse 15A 832-1812 832-1812 832-1812 832-2241 832-2241 832-2241
Burner Sight Glass 851-26 851-26 851-26 851-26 851-26 851-26
Retainer, Sight Glass 65-879 65-879 65-879 65-879 65-879 65-879
Gasket, Sight Glass (2) 853-213 853-213 853-213 853-213 853-213 853-213
To Next Page
