Chapter 1 — Introduction
Part No. 750-263 1-5
When standing at the back of the boiler, the stack can be connected
on the right side of the boiler (Figure 1-12) or on the left side (Figure
1-13). Refer to Chapter 3 of this manual for recommended vent
sizes and lengths for the specific boiler installation.
6. Optional Equipment
Certain options may have been supplied with the boiler that are
relative to the project requirements if these options were specified
with the boiler at the time of order entry. Also, some options may
have been provided [by others] that are not part of Cleaver-Brooks
scope of supply. In either case, the Cleaver-Brooks authorized
representative should be consulted for project specifics.
These are the options that are available for the CFC boiler from
Cleaver-Brooks:
A. Reusable air filter.
B. Condensate neutralization treatment tank assembly -
consists of neutralizing media, filter, and PVC condensate
holding tank. This assembly is mounted beneath the boiler
and is further described in Chapter 2.
C. Outside air intake for direct vent combustion.
D. Outdoor temperature sensor for indoor/outdoor control.
E. Shipped loose Auxiliary Low Water Control for field piping
by others into the system piping.
F. Alarm Horn for safety shutdown.
G. Relays for output signal for burner on, fuel valve open.
H. Stack Thermometer.
I. Stack temperature limit-sensor.
J. Common condensate drain trap.
Table 1-1 Model CFC Water Temperature Data
Minimum supply temp. 33
o
F
Maximum operating temp. 194
o
F
Maximum design temp. 210
o
F
