CleaverBrooks CFC User Manual

Chapter 4 — CFC Commissioning
4-6 Part No. 750-263
Table 4-1 CB Falcon factory parameter settings - Model CFC
Parameter Group Parameter Name Access
Min.
Range Default Setting Max. Range
Parameter
Units
Installation
Setting
System ID & Access Boiler Name Service Boiler 1
System ID & Access Installation data Service CFC
System ID & Access Installer password Service 9220
System ID & Access OEM Identification Read Only MB00xxxx
System ID & Access Modbus address Service 0 2 250
System ID & Access Factory data Read Only CFC
Statistics Configuration Burner cycle count Read Only 0 999,999
Statistics Configuration Burner run time Read Only 0 999,999
Statistics Configuration CH pump cycle count Read Only 0 999,999
Statistics Configuration DHW pump cycle count Read Only 0 999,999
Statistics Configuration System pump cycle count Read Only 0 999,999
Statistics Configuration Boiler pump cycle count Read Only 0 999,999
Statistics Configuration Auxiliary pump cycle count Read Only 0 999,999
System Configuration Temperature units Service Fahrenheit
System Configuration Antishort cycle time Service 0 60 28800 seconds
System Configuration Alarm silence time Service 0 0 3600 seconds
System Configuration Modulation Output Read Only VSD Fan PWM
Modulation Configuration CH max. mod. rate Service 2000 See Table 4-2 6000 RPM
Modulation Configuration DHW max. mod. rate Service 2000 See Table 4-2 6000 RPM
Modulation Configuration Minimum mod. rate Service 900 See Table 4-2 3000 RPM
Modulation Configuration CH forced rate Service 1000 2000 6500 RPM
Modulation Configuration CH forced rate time Service 0 0 14400 seconds
Modulation Configuration DHW forced rate Service 1000 2000 6500 RPM
Modulation Configuration DHW forced rate time Service 0 0 14400 seconds
Modulation Configuration Analog output hysteresis Service 0 5 20
Modulation Configuration CH slow start enable Service Disabled
Modulation Configuration DHW slow start enable Service Disabled
Modulation Configuration Slow start ramp Service 100 200 1000 RPM
Modulation Configuration Slow start setpoint Service 0 20 180
Modulation Configuration Burner switch User Off
Modulation Configuration Firing rate control User Auto
Modulation Configuration Manual firing rate User 900 2000 6500 RPM
Fan Configuration Absolute max. fan speed Read Only 6000 RPM
Fan Configuration Absolute min. fan speed Read Only 900 RPM
Fan Configuration PWM frequency Read Only 3000 Hz
Fan Configuration Pulses per revolution Read Only 3
Fan Configuration Fan speed up ramp Service 0 0 1000 RPM/sec
Fan Configuration Fan speed down ramp Service 0 0 1000 RPM/sec
Fan Configuration Fan gain up Service 0 30 100
Fan Configuration Fan gain down Service 0 30 100
Fan Configuration Fan min. duty cycle Service 5 10 100 %
