Figure 1 - 3
LCD Panel Open
Models B/D
1. Built-In PC Camera
(
Optional
)
2. PC Camera LED
3. LCD
4. Power Button
5. LED Status
Indicators
6. Keyboard
7. Built-In Microphone
8. Touchpad &
Buttons
Note that the Touchpad and
Buttons valid operational area
is that indicated within the red
dotted lines above.
8
3
1
8
4
6
Wireless Device
Operation Aboard
Aircraft
The use of any portable elec-
tronic transmission devices
aboard aircraft is usually pro-
hibited. Make sure the mod-
ule(s) are OFF if you are using
the computer aboard aircraft.
Use the key combinations to
toggle power to the WLAN/
Bluetooth modules, and
check the LED indicator or on-
screen icon to see if the mod-
ules are powered on or not
(see Table , on page 1 - 12/
Table 1 - 3, on page 1 - 9).
