page 75 of 120
ARRI Amira:
Note: This set-up will require 2x cPRO motor, 2x cPRO camin, or a combination of both if
camera control is also being used.
Cables required: [K2.0015756] Cable CAM (7p) - EXT (6p) (camera control)
[K2.0015759] Cable CAM (7p) - ENG (12p) (data feed)
Power splitter cable recommended: [K2.0023823] Cable LBUS Star (0.2m/8in)
[C0JE-K79] Cable LBUS Star-2 (0.4m/16in)
Note: LBUS Star is a splitter cable that can be positioned anywhere within the LBUS daisy
chain to supply extra power from an additional power source.
All RED cameras:
Cable required: [K2.0015758] Cable CAM (7p) - RED CTRL/D-Tap
(camera control + data feed)
NOTICE
In order to allow metadata feed from the cPRO LCS to the RED camera, the REDLINK
Command Protocol needs to be enabled; - Settings/Setup/Communication/Serial -> select
REDLINK Command Protocol in the drop down menu.
