10. Feed the Left end of the
Drive Roller Unit Shaft into
the hole in the Left End Plate,
and lower the Drive Roller
Unit into the recess.
11. Insert the right end of the
Drive Roller Unit Shaft into
the appropriate hole in the
Right End Plate against the
locking washers.
12. Refit the bearing and spring
washer and press into the
hole in the Left End Plate.
13. Refit the 2 x M3 locking
screws and washers.
