Colortrac M25e - Page 85

M Series Service Manual
Page 85 of 129
3. Pull the Main Timing Belt off
from the Drive Roller Pulley.
4. Remove the Main Timing Belt
by lifting off from the Motor
Pulley.
5. To refit the Main Timing Belt
loop the belt and feed up
through the Motor Bracket.
6. Fit the Main Timing Belt over
the Motor Pulley.
