8. Reconnect the cables to the
Power Switch Terminals
pushing firmly in place with
pliers.
9. Make sure the wires are fitted
in the correct terminals as
shown.
10. Refit the Main Board Cover
as described in chapter “14.1
Main Board” page 45.
11. Refit the Top Lid Cover as
described in chapter “13.4
Top Lid Cover” page 24.
