Compaq Armada 1100 Reference Guide

. . . . . . . . . . . . . . . . . . . . . . . . .
C-2
Connector Pin Assignments
Part Number:262446-001 Writer: Dianne Fielden Saved by: JohnnieA
Saved Date: 02/26/96 1:26 PM 12:17 PM File Name: APPC.DOC
Serial Connector
Connector Pin Signal
1
2
6
3
4
5
7
8
9
1
2
3
4
5
6
7
8
9
Carrier Detect
Receive Data
Transmit Data
Data Terminal Ready
Ground
Data Set Ready
Ready to Send
Clear to Send
Ring Indicator
Keyboard/Mouse Connector
Connector Pin Signal
1
2
4
6
5
3
1
2
3
4
5
6
Data
Reserved
Ground
+ 5V
Clock
Reserved
