Connector Pin Assignments
C-5
Part Number:262446-001 Writer: Dianne Fielden Saved by: JohnnieA
Saved Date: 02/26/96 1:26 PM 12:17 PM File Name: APPC.DOC
PC Card (PCMCIA) Connector
Continued
Pin Signal Pin Signal
47
Address bit 18
58 Card reset
48
Address bit 19
59 Extend bus cycle
49
Address bit 20
60 Input port acknowledge
50
Address bit 21
61 Register select and IO
enable
51
Power
62 Battery voltage detect
2/Audio digital waveform
52
Programming and
peripheral supply 2
63
Battery voltage detect
1/Card status changed
53
Address bit 22
64
Data bit 8
54
Address bit 23
65
Data bit 9
55
Address bit 24
66
Data bit 10
56 Address bit 25
67
Card detect 2
57 Reserved 68
Ground
