97
VECTOR
PLAYBACK
Viewing the Playback Displays
Playback device displays are opened from the Workspace tree
(See:“
Using the Workspace tree” on page 20). Playback displays
include:
:
To open a playback display
1. Make sure the active pane is the pane where you want the playback
display to appear.
2. Open the
Workspace tree.
3. Expand the
Playback node and tap the playback you want to view.
Figure 29: Playback wing 1 display (partial)
Continued on next page...
• Wing 1 • Individual playback 1 devices
• Wing 2 • Individual playback 2 devices
• Qkeys 1 • Individual QKey 1 devices
• Qkeys 2 • Individual QKey 2 devices
• AB Playback • AB playback device
• Master PB • Master playback device
Note: PB Q-KEY/ DISPLAY toggles between Fader Wing and QKey displays.
