60
Compulite
Chapter 3
To set values using the numeric keypad
Example: Set dimmer at 60%, pan at 40, tilt at 35, and cyan at 20.
1. Select the fixtures.
2. Press
@, 60, ENTER.
The dimmer intensity is set to 60%.
3. Press
POSITION, PAN, @, 40, ENTER.
The position is updated with the new value.
4. Press
TILT, @, 35, ENTER.
The position is updated with the new value
5. Press
COLOR, CYAN, @, 20, ENTER.
The color is updated with the new value
Note: There are dedicated keys for FULL (100%), ON (50%), and ZERO
(zr).
