UT-4500 Series C- and Ku-Band Up Converters MN/UT4500.IOM
Front Panel Operation Revision 3
6–14
6.2.3.3 (CONFIG:) REDUNDANCY Submenu
See Appendix A. REDUNDANT SYSTEM OPERATION for detailed
information about using the front panel menus for redundancy
configuration and operation.
This menu branch is functional in LOCAL MODE ONLY.
1:1 Redundancy is an optional feature for the UT-4500. If you attempt to select
any feature from this menu branch, and either Redundancy Configuration is off
or the converter is the primary operating unit, the Redundancy menu branch
appears as follows:
Redundancy: MODE
Otherwise:
Redundancy: MODE
Auto/Manual FORCE HSB
Use the keys to select MODE, Auto/Manual, FORCE, or HSB (High Speed
Bus). Press ENTER.
6.2.3.3.1 (REDUNDANCY:) MODE
Redundancy Config = On
CONVERTER = #BU 1:01
On the top line, use the keys to select the Redundancy Config setting, and
then use the keys to toggle operation as On or Off.
On the bottom line, when Redundancy Mode = On, use the keys to navigate
to the Converter Selection setting, and then use the keys to toggle the
converter operational preference as #BU (the backup up converter) or online
converter #01 through #12.
