UT-4500 Series C- and Ku-Band Up Converters MN/UT4500.IOM
Specifications Revision 3
2–6
CEFD P/N
Impedance
(Ohms)
Comments
AS/0101-31 75 DT-4513, UT-4514/F w/Isolator, Type ‘SMA’
AS/0101-32 50 DT-4513, UT-4514/F w/Isolator, Type ‘SMA
AS/0101-33 75 DT-4513, UT-4518/F w/Isolator, Type ‘SMA’
AS/0101-34 50 DT-4513, UT-4518/F w/Isolator, Typr ‘SMA’
AS/0101-41
50
DT-4513 1:1 Switching
2.1.8.5.5 RSM (Receive Switch Module) Assemblies
CEFD P/N
Impedance
(Ohms)
Comments
AS/0101-4
75
DT-4503 Switching, Down, Type ‘SMA’
AS/0101-6
75
DT-4503, DT-4572, UT-4579 Switching, Type ‘N’
AS/0101-7
50
DT-4503, DT-4572, UT-4579 Switching, Type ‘N’
AS/0101-16
50
DT-4503 I/O, Type ‘SMA’
AS/0101-20
75
Receive Switch, RSM2
AS/0101-26
50
RSM2, Type ‘N’
AS/0101-37
50
DT-451X w/Isolator, Type ‘SMA’
AS/0101-38 75 DT-451X w/Isolator, Type ‘SMA’
2.2 Operational Specifications
Specificiations are typical for all products unless noted.
2.2.1 Available Models / Operating Frequency Ranges
Contact Comtech EF Data Product Support for your specific requirements.
2.2.1.1 C-Band Units
• UT-4505: 5845 to 6425 MHz
• UT-4505/E: 6725 to 7025 MHz
• UT-4505/F: 6425 to 6725 MHz
• UT-4505/G: 5925 to 6725 MHz
• UT-4505/H: 5850 to 6650 MHz
• UT-4505/I: 5845 to 6725 MHz
