UT-4500 Series C- and Ku-Band Up Converters MN/UT4500.IOM
Specifications Revision 3
2–10
2.2.9.3 Gain Stability
± 0.25 dB/day
2.2.9.4 Ripple
Contact Comtech EF Data Product Support for your specific requirements.
• ±0.25 dB (±18 MHz) – OPTIONAL ±20 MHz
• 0.75 dB (±36 MHz) – OPTIONAL ±40 MHz
2.2.9.5 Slope
0.05 dB/MHz
2.2.9.6 IF Bandwidth
Contact Comtech EF Data Product Support for your specific requirements.
• STANDARD: 36 or 72 MHZ
• OPTIONAL: 40 or 80 MHz
2.2.10 Group Delay
2.2.10.1 Linear
0.03ns/MHz
2.2.10.2 Parabolic
0.01ns/MHz
2
2.2.10.3 Ripple
1.0ns Peak-to-Peak
