2.2.11 Phase Noise
2.2.11.1 UT-4505
Parameter Limit (dBc/Hz) Typical (dBc/Hz)
100 Hz
-80
-83
1 KHz -89 -92
10 KHz -95 -97
100 KHz
-105
-109
1 MHz -120 -124
2.2.11.2 UT-4505/E, UT-4505/F, UT-4505/G, UT-4505/H,
UT-4505/I, UT-4505/J, UT-4505/K, UT-4505/M,
UT-4505/N
Parameter
Limit (dBc/Hz)
Typical (dBc/Hz)
100 Hz -69 -72
1 KHz
-79
-82
10 KHz
-89
-92
100 KHz -99 -102
1 MHz -109 -112
2.2.11.3 UT-4514
Parameter Limit (dBc/Hz) Typical (dBc/Hz)
100 Hz -72 -79
1 KHz
-79
-82
10 KHz -89 -92
100 KHz
-98
-101
1 MHz
-110
-114
2.2.11.4 UT-4514/F, UT-4518, UT-4518/E
Parameter Limit (dBc/Hz) Typical (dBc/Hz)
100 Hz
-66
-69
1 KHz -76 -79
10 KHz -86 -89
100 KHz
-96
-99
1 MHz -106 -109
