7.4.2 HTTP Interface Features
7.4.2.1 Menu Tree
Figure 7-5 Illustrates the menu hierarchy for the HTTP Interface. It features four
navigation tabs (shown in blue). Primary page hyperlinks (grey) grant access to
individual web pages.
Home Admin Config Status
Home Access Converter Summary
Contact SNMP Ref Faults
Support Pre-Selects
Utility
Redundancy
Figure 7-5. HTTP Interface Menu Tree (FW Ver. 1.3.4)
7.4.2.2 Page Navigation
The HTTP Interface has four navigation tabs at the top of each page. Click a
navigation tab to see its page hyperlinks. Click a page hyperlink to open a page.
This manual uses a convention for all web pages to show
you how to navigate to the featured page: Navigation Tab
| Page Hyperlink. For example, “Home | Home” instructs
you to click the ‘Home’ navigation tab, and then select the
‘Home’ page hyperlink.
7.4.2.3 Page Sections
This manual explains the purpose and operation for each
Web page and its sections. Each page has one or more
sections. The title at the upper-left corner of each page or
section describes its operational features. Each section can
have editable fields, action buttons and read-only displays
for a specific function.
