UT-4500 Series C- and Ku-Band Up Converters MN/UT4500.IOM
Front Panel Operation Revision 3
6–20
Once the number of faults reaches 100, the 100
th
fault displays as “ER.” The
stored faults remain in memory until you execute the CLEAR-ALL command.
Press ENTER or CLEAR to return to the previous menu.
6.2.5.2.2 (FAULTS:) STOREDCLEAR-ALL
Clear All Stored Faults
No Yes
Use the keys to select No or Yes. Press ENTER.
When you select Yes, the unit clears the faults log and returns you to the
previous menu. However, if there are faults present on the unit at this time, the
unit will re-stamp the faults and generate new log entries.
6.2.5.3 (FAULTS:) MASK
The MASK selection is disabled in redundancy systems.
Ext Ref Lock Detect:
Fault Masked
Set the fault handling for the External Reference, when applicable. Use the
keys to select Fault or Masked. Press ENTER.
6.2.6 (SELECT:) PRE-SELECTS Menu Branch
You may create (program) up to 32 operating configurations and recall them as
needed via the LOAD submenu. If your unit does not contain any pre-selects, the
screen initially appears as follows:
#XX LOAD PROGRAM CLEAR
No Pre-Select Programmed
