1.3 Up Converter Features
1.3.1 Physical Description
The UT-4500 features a 1RU-high (1.75”) 19-inch wide chassis that is designed
for rack mounting into a standard 19-inch (48.26 cm) equipment rack. The unit
may also be mounted into the rack using the provided slide mechanisms to allow
service without removal from the rack. The unit may be freestanding if desired.
For: See:
• Rack installation and
mounting instructions
Chapter 3. INSTALLATION
• Local control operating
instructions and procedures
Chapter 6. FRONT PANEL
OPERATION
• Remote control operating
instructions and procedures
Chapter 7. ETHERNET INTERFACE
OPERATION and
Chapter 8. SERIAL INTERFACE
OPERATION
•
Redundant system operating
instructions and procedures
Appendix A. REDUNDANT
SYSTEM OPERATION
• Maintenance and
troubleshooting procedures
Appendix B. MAINTENANCE AND
TROUBLESHOOTING
