Comtech EF Data UT-4500 Series - PACRMS (Packed Maintenance Status); PACRAS (Packed Alarm Status)

UT-4500 Series C- and Ku-Band Up Converters MN/UT4500.IOM
Serial Interface Operation Revision 3
8–30
4) If the converter is the primary converter, gg=P1 or P2 (single or
dual polarity system).
8.7.5.8 PACRMS (Packed Maintenance Status)
Description
Details
Maintenance Status:
<DEV/PACRMS_{cr}
Confirmation:
>DEV/PACRMS_aabbccddeeeffgghhii{cr}{lf}] where:
aa = V15 scaled 123mV per count (0x00 - 0xFF)
bb = V14 scaled 123mV per count (0x00 - 0xFF)
bc = VCC scaled 39mV per count (0x00 - 0xFF)
dd = V5D scaled 39mV per count (0x00 - 0xFF)
eee = signed Temperature in degrees C (-10 to +60)
ff = IFLO tune scaled 67mV per count (0x00 - 0xFF)
gg = SUM tune scaled 54mV per count (0x00 - 0xFF)
hh = COARSE tune scaled 78mV per count (0x00 - 0xFF)
ii = FINE tune scaled 89mV per count (0x00 - 0xFF)
l = 1 if Remote Mode, 0 if Local Mode
8.7.5.9 PACRAS (Packed Alarm Status)
Description
Details
Alarm Status:
<DEV/PACRAS_{cr}
Confirmation:
>DEV/PACRAS_abcdefghijk{cr}{lf}] where:
a = 1 if V15 Fault, else 0 if No Fault
b = 1 if V14 Fault, else 0 if No Fault
c = 1 if VCC Fault, else 0 if No Fault
d = 1 if V5D Fault, else 0 if No Fault
e = 1 if TEMP Fault, else 0 if No Fault
f = 1 if IFLO Fault, else 0 if No Fault
g = 1 if SUM Fault, else 0 if No Fault
h = 1 if COARSE Fault, else 0 if No Fault
I = 1 if FINE Fault, else 0 if No Fault
j = 1 if HSB Fault, else 0 if No Fault
k = 1 if EXT REF Fault, else 0 if No Fault
