28 Mentor ll User Guide
www.controltechniques.com Issue Number: 12
Menu 00 User Library - Refer to Menu 11
Contains ten parameters (00.01 to 00.10).The user sets parameters 11.01 to 11.10 to any parameter numbers most often required or used. These can
then be accessed directly through the corresponding numbers 00.01 to 00.10, avoiding the need to call up different menus.
Menu 01 Speed Reference - selection of source and limits
Menu 02 Acceleration and Deceleration Ramps
Number Description Range Type Default
01.01 Pre-offset speed reference ±1000 RO
01.02 Post-offset speed reference ±1000 RO
01.03 Pre-ramp reference ±1000 RO
01.04 Offset ±1000 RW + 000
01.05 Inch reference ±1000 RW + 050
01.06 Maximum speed forward 0 ~ +1000 RW +1000
01.07 Minimum speed forward 0 ~ +1000 RW + 000
01.08 Minimum speed reverse -1000 ~ 0 RW + 000
01.09 Maximum speed reverse (4Q) -1000 ~ 0 RW - 1000
(1Q) -1000 ~ 0 RW 000
01.10 Bipolar reference selector (4Q) 0 or 1 RW 1
(1Q) 0 or 1 RW 0
01.11 Reference “ON” 0 or 1 RW 0
01.12 Reverse selector 0 or 1 RW 0
01.13 Inch selector 0 or 1 RW 0
01.14 Reference selector 1 0 or 1 RW 0
01.15 Reference selector 2 0 or 1 RW 0
01.16 Zero reference interlock 0 or 1 RW 0
01.17 Reference 1 ±1000 RW (07.15)
01.18 Reference 2 ±1000 RW + 300
01.19 Reference 3 ±1000 RW (07.13)
01.20 Reference 4 ±1000 RW (07.14)
Number Description Range Type Default
02.01 Post-ramp reference ±1000 RO
02.02 Ramp enable 0 or 1 RW 1
02.03 Ramp hold 0 or 1 RW 0
02.04 Forward acceleration 1 0 ~ 1999 RW + 050
02.05 Forward deceleration 1 0 ~ 1999 RW + 050
02.06 Reverse deceleration 1 (4Q) 0 ~ 1999 RW + 050
(1Q) 0 ~ 1999 RW 000
02.07 Reverse acceleration 1 (4Q) 0 ~ 1999 RW + 050
(1Q) 0 ~ 1999 RW 000
02.08 Forward acceleration 2 0 ~ 1999 RW + 100
02.09 Forward deceleration 2 0 ~ 1999 RW + 100
02.10 Reverse deceleration 2 (4Q) 0 ~ 1999 RW + 100
(1Q) 0 ~ 1999 RW 000
02.11 Reverse acceleration 2 (4Q) 0 ~ 1999 RW + 100
(1Q) 0 ~ 1999 RW 000
02.12 Inch ramp rate 0 ~ 1999 RW + 100
02.13 Enable inch ramp 0 or 1 RW 0
02.14 Forward acceleration selector 0 or 1 RW 0
02.15 Forward deceleration selector 0 or 1 RW 0
02.16 Reverse deceleration selector 0 or 1 RW 0
02.17 Reverse acceleration selector 0 or 1 RW 0
02.18 Common ramp selector 0 or 1 RW 0
02.19 Ramp scaling (x 10) 0 or 1 RW 0
