36 Mentor ll User Guide
www.controltechniques.com Issue Number: 12
Menu 10 Status Logic & Diagnostic Information
Number Description Range Type Default
10.01 Forward velocity 0 or 1 RO
10.02 Reverse velocity 0 or 1 RO
10.03 Current limit 0 or 1 RO
10.04 Bridge 1 enabled 0 or 1 RO
10.05 Bridge 2 enabled 0 or 1 RO
10.06 Electrical phase-back 0 or 1 RO
10.07 At speed 0 or 1 RO
10.08 Overspeed 0 or 1 RO
10.09 Zero speed 0 or 1 RO
10.10 Armature voltage clamp active 0 or 1 RO
10.11 Phase rotation 0 or 1 RO
10.12 Drive healthy (normal) 0 or 1 RO
10.13 Alarm (I x t) 0 or 1 RO
10.14 Field loss 0 or 1 RO
10.15 Feedback loss 0 or 1 RO
10.16 Supply or phase loss 0 or 1 RO
10.17 Instantaneous trip 0 or 1 RO
10.18 Sustained overload 0 or 1 RO
10.19 Processor 1 watchdog 0 or 1 RO
10.20 Processor 2 watchdog 0 or 1 RO
10.21 Motor overtemperature 0 or 1 RO
10.22 Heatsink overtemperature 0 or 1 RO
10.23 Speed loop saturated 0 or 1 RO
10.24 Zero current demand 0 or 1 RO
10.25 Last trip 0 ~ 255 RO
10.26 The trip before last trip (10.25) 0 ~ 255 RO
10.27 The trip before 10.26 0 ~ 255 RO
10.28 The trip before 10.27 0 ~ 255 RO
10.29 Disable field loss trip 0 or 1 RW 0
10.30 Disable feedback loss trip 0 or 1 RW 0
10.31 Disable supply or phase loss trip 0 or 1 RW 0
10.32 Disable motor overtemperature trip 0 or 1 RW 1
10.33 Disable heatsink overtemperature trip 0 or 1 RW 0
10.34 External trip 0 or 1 RW 0
10.35 Processor 2 trip 0 ~ 255 RW 0
10.36 Disable current loop loss trip 0 or 1 RW 0
10.37 Disablearmatureopencircuittrip 0or1 RW 0
