Control Techniques Mentor II User Manual

Mentor ll User Guide 35
Issue Number: 12 www.controltechniques.com
Menu 09 Status Outputs
Number Description Range Type Default
09.01 Status 1 output 0 or 1 RO
09.02 Status 2 output 0 or 1 RO
09.03 Status 3 output 0 or 1 RO
09.04 Status 4 output 0 or 1 RO
09.05 Status 5 output 0 or 1 RO
09.06 Status 6 output (relay) 0 or 1 RO
09.07 Status 1 source 1 0 ~ 1999 RW + 111
09.08 Invert status 1 source 1 0 or 1 RW 0
09.09 Status 1 source 2 0 ~ 1999 RW 000
09.10 Invert status 1 source 2 0 or 1 RW 0
09.11 Invert status 1 output 0 or 1 RW 0
09.12 Status 1 delay 0 ~ 255 sec RW 00
09.13 Status 2 source 1 0 ~ 1999 RW + 1007
09.14 Invert status 2 source 1 0 or 1 RW 0
09.15 Status 2 source 2 0 ~ 1999 RW 000
09.16 Invert status 2 source 2 0 or 1 RW 0
09.17 Invert status 2 output 0 or 1 RW 0
09.18 Status 2 delay 0 ~ 255 sec RW 0
09.19 Status 3 source 0 ~ 1999 RW +1013
09.20 Invert status 3 output 0 or 1 RW 0
09.21 Status 4 source 0 ~ 1999 RW +1003
09.22 Invert status 4 output 0 or 1 RW 0
09.23 Status 5 source 0 ~ 1999 RW +1006
09.24 Invert status 5 output 0 or 1 RW 0
09.25 Status 6 source (relay) 0 ~ 1999 RW +1009
09.26 Invert status 6 output 0 or 1 RW 0
