Control Techniques Mentor II User Manual

Mentor ll User Guide 57
Issue Number: 12 www.controltechniques.com
Determines the source of the IR Compensation 2. The source selection
may be either the Speed Error Integral 03.08 (set to 0) or the final
current demand 04.02 (set to 1).
Restricts the advance of the firing angle in cases where 180
o
advance
would result in overvoltage being applied to the field windings.
Thiscanbeusedwhenthesupplyvoltageismuchhigherthanthe
required field voltage to prevent an overvoltage condition.
Where:
V
DC
= Required field voltage
V
S
= Supply voltage
Provides the option of full or half control. Available only with the FXM5
Field Controller. To use FXM5 in Full Control mode, set 06.22 =1and
LK3 to Full Control position.
Setting this parameter to 1 reduces the field current gains by a factor of
2.
Setting this parameter to 1 reduces the field current gains by a factor of 4
Setting both 6.23 and 6.24 to 1 will result in the gains being reduced by
8.
06.20 Alternative IR comp. 2 selector
RW Bit
ô
0or1
ð
0(=03.08)
06.21 Firing angle front endstop
RW Uni
ô
0 ~ 1000
ð
+1000
06.22 Full or half control selector
RW Bit
ô
0or1
ð
0, half control
06.23 Reduce gains by factor of 2
RW Bit
ô
0or1
ð
0
06.24 Reduce gains by factor of 4
RW Bit
ô
0or1
ð
0
06.21 1023
768
180
°
------------
1–
cos
Vdcπ
2Vs
---------------
èø
æö
1–
–=
