Selects the destination of analog input 1 via terminal TB1-04.
A changed value becomes effective only when the RESET pushbutton is
pressed.
Selects the destination of analog input 2 via terminal TB1-05.
A changed value becomes effective only when the RESET pushbutton is
pressed.
Selects the destination of analog input 3 via terminal TB1-06.
A changed value becomes effective only when the RESET pushbutton is
pressed.
Selects the destination of analog input 4 via terminal TB1-07.
A changed value becomes effective only when the RESET pushbutton is
pressed.
Selects the destination of speed reference 07.05.
A changed value becomes effective only when the RESET pushbutton is
pressed.
Sets the scaling for the signal from source GP1 via terminal TB1-04.
Sets the scaling for the signal from source GP2 via terminal TB1-05.
Sets the scaling for the signal from source GP3 via terminal TB1-06.
Sets the scaling for the signal from source GP4 via terminal TB1-07.
The factor by which 07.05 is multiplied to produce the speed reference.
Sets the scaling for signals output from DAC1 TB2-12.
Sets the scaling for signals output from DAC2 TB2-13.
Sets the scaling for signals output from DAC3 TB2-14.
07.11 GP1 destination
RW Uni
ô
0 ~ 1999
ð
+318, hard speed ref.
07.12 GP2 destination
RW Uni
ô
0 ~ 1999
ð
+408, torque ref.
07.13 GP3 destination
RW Uni
ô
0 ~ 1999
ð
+119, speed ref. 3
07.14 GP4 destination
RW Uni
ô
0 ~ 1999
ð
+120, speed ref. 4
07.15 Speed reference destination
RW Uni
ô
0 ~ 1999
ð
+117, speed ref. 1
07.16 GP1 scaling
RW Uni
ô
0 ~ 1999
ð
+1000
07.17 GP2 scaling
RW Uni
ô
0 ~ 1999
ð
+1000
ScalingFactor
07.16
1000
---------------
=
ScalingFactor
07.17
1000
---------------
=
07.18 GP3 scaling
RW Uni
ô
0 ~ 1999
ð
+1000
07.19 GP4 scaling
RW Uni
ô
0 ~ 1999
ð
+1000
07.20 Speed reference scaling
RW Uni
ô
0 ~ 1999
ð
+1000
07.21 DAC 1 scaling
RW Uni
ô
0 ~ 1999
ð
+1000
07.22 DAC 2 scaling
RW Uni
ô
0 ~ 1999
ð
+1000
07.23 DAC 3 scaling
RW Uni
ô
0 ~ 1999
ð
+1000
ScalingFactor
07.18
1000
---------------
=
ScalingFactor
07.19
1000
---------------
=
ScalingFactor
07.20
1000
---------------
=
ScalingFactor
07.21
1000
---------------
=
ScalingFactor
07.22
1000
---------------
=
ScalingFactor
07.23
1000
---------------
=
