Chapter 2 Servo Specifications
6
Chapter 2 Servo Specifications
2.1 Servo Drive Specification
Model
C600S-40
C600S-75
Power
0.05KW~0.4KW
0.75KW~1KW
Main
Circuit
1 phase AC220V-15%~+10% 50/60Hz
Control
Mode
0：Position. 1：Speed. 2：Torque. 3：Position and speed. 4：Position and torque. 5：Speed
and torque
Protection
Function
Over speed, Over voltage, Under voltage,Overload, Abnormal of main power, Abnormal
encoder, Out of position error etc.
Monitor
Function
Speed, Current position, Command pulse accumulation,Position deviation, Motor torque,
Motor current, Running state etc.
Control
Input
1
：
Servo on 2
：
Alarm clearance 3
：
CCW drive inhibition 4
：
CW drive inhibition 5
：
Deviation counter clearance 6
：
Command pulse inhibition 7
：
CCW torque limit 8
：
CW torque limit
Control
Output
Servo ready/Servo alarm/Positioning completion/Mechanical braking
Regenerati
on Braking
Built-in/ Built-out
Load
Less than 3 times of motor torque
Display
5 LED digital display and 4 keys
Communic
ation
RS485
Position
Control
Mode
Input Mode
0：pulse+direction
1
：
CCW/CW pulse
2：A/B phase orthogonal pulse
3
：
Internal position control
Electronic gear ratio
1-32767/1-32767
