Chapter 4 Drive System Wiring And Introduction
16
4.4 Control Signal Terminal
4.4.1 Terminal Introduction
The control signal terminals provide the signals needed to connect to the higher-level controller,
using bent press-on double-row 3.5mm pitch terminals, and the signals include:
 4 programmable input terminals
 4 programmable output terminals
 Analog command inputs
 Pulse command inputs
4.4.2 CN1 terminal pin distribution
Pic 4.4 Terminal Pin Distribution
 A 24-26 AWG cable is recommended.
