Chapter 4 Drive System Wiring And Introduction
12
However, by exchanging three-phase terminal cannot cause the motor to reverse; this point
is different with asynchronous motor.
 Earthed wiring must be reliable with a single-point connection.
 Pay attention to the correct direction of freewheel diode which is connected with the delay
at the output terminal, other can cause the output circuit breakdown.
 In order to protect the servo driver from noise interference that can cause malfunction,
please use an insulation transformer and noise filter on the power lines.
 Wiring the power cables(power supply , main circuit ,etc) at a distance over 30cm away
from the control signal cables, do not lay them together.
 Install a non-fuse circuit breaker that can shut off the external power supply immediately
for in case of the servo driver fault.
4.1.3 Electric Wire Specifications
Connect Terminal
Symbol
Wire Specification
Main Power Supply
L1、L2
1.5~4mm
2
Servo Motor
U、V、W
1.5~4mm
2
Ground
PE
1.5~4mm
2
Control Signals
≧
0.14mm2(AWG26), Shielded.
Encoder Signals
CN1
≧0.14mm2(AWG26), Shielded.
Regenerative
Resistors Terminals
P、D/P、C
1.5~4mm
2
 Must use a twisted pair wire cable for the encoder signal wiring. If the encoder
signal cable is too long(＞20m), in which the encoder power supply can be
insufficient, may use multi wires or thick wire for the power supply wiring.
