Coolmay C600S - Parameter Settings in Position Mode

Chapter 5 Running Mode And Controlling Wiring
36
5.1.3 Parameter Settings In Position Mode
 Gain And Smooth Filter
Parameter
Introduction
Range
Default Value
FA4
Control mode
0
0
FA9
Position Proportional Gain
1-1000
80
FA19
Position Command Smooth Filter
0-1000×0.1ms
100
FA100
Command Filter Selection
0-1
0
 Digital Input
Parameter
Introduction
Range
Default Value
FA11
Command pulses for each rotation
0-30000
10000
FA12
1
st
numerator of electronic gear for position
command pulse
1-32767
0
FA13
Denominator of electronic gear for position
command pulse
1-32767
10000
FA14
Input mode of position command pulse
0-3
0
FA15
reverse direction of position command pulse
0-1
0
FA59
The effective edge of command pulse
0-1
0
FA77
2
nd
numerator of electronic gear for position
pulse
1-32767
0
FA78
3
rd
numerator of electronic gear for position
pulse
1-32767
0
FA79
4
th
numerator of electronic gear for position
pulse
1-32767
0
FA80
Effective level of command direction signal
0-1
0
FA81
Command pulse(PULS)signal filter
0-15
4
FA82
Command pulse(SIGN)signal filter
0-15
4
