Chapter 7 Parameters
7.2 F3 Group Parameters For Multifunctional Terminals
7.2.1 Parameter Table
C series servo drives have 4 input terminals and 4 output terminals. The definition values
can be set by F3 group parameters.( Low level is effective as default for input terminals).
which can add a programmable output and output
differential signal (Z signal is as default).
Digital input DI1 function
Digital input DI2 function
Digital input DI3 function
Digital input DI4 function
Digital input DI5 function
Digital input DI6 function
Low 16-bit current position value
High 16-bit current position value
Digital input DI forced effective1
Digital input DI forced effective2
Digital input DI forced effective3
Digital input DI forced effective4
Digital input DI forced effective5
Digital output DO1 function
Digital output DO2 function
Digital output DO3 function
Digital output DO4 function
Digital output DO5 function
