Chapter 3 Drive And Motor Dimension
9
Chapter 3 Drive And Motor Dimension
3.1 Drive Dimension
Pic 3.1 C600S-40/C600S-75 Series Dimension Drawing
3.2 Motor Dimension
● Installation dimensions of 60 frame motor (see Figure 3.2 and table 3-1)
The base of the C600S-40 does not have a cooling fan.
