Coolmay C600S - DI Forced Valid

Chapter 7 Parameters
86
Completion
command doesn’t stop.
ON: The signal outputs after the setting time of F4-1
when internal position command completes or internal
position command stops.
7.2.4 DI Forced Valid
There are 5 parameters( F3-15
、
F3-16
、
F3-17
、
F3-18
、
F3-19) in group F3 and they can
force DI valid.
(1) Corresponding functions for F3-15 is represented by 8-bit binary:
Number
Bit7
Bit6
Bit5
Bit4
Bit3
Bit2
Bit1
Bit0
Function
CZERO
ZCLAMP
TCW
TCCW
CWL
CCWL
ARST
SON
(2) Corresponding functions for F3-16 is represented by 8-bit binary:
Number
Bit7
Bit6
Bit5
Bit4
Bit3
Bit2
Bit1
Bit0
Function
CMODE
NULL
TRQ2
TRQ1
NULL
SF2
SF1
CINV
(3) Corresponding functions for F 3-17 is represented by 8-bit binary:
Number
Bit7
Bit6
Bit5
Bit4
Bit3
Bit2
Bit1
Bit0
Function
NULL
JOGN
JOGP
INH
CLR
GEAR2
GEAR1
NULL
(4) Corresponding functions for F3-18 is represented by 8-bit binary:
Number
Bit7
Bit6
Bit5
Bit4
Bit3
Bit2
Bit1
Bit0
Function
NULL
POS2
POS1
POS0
CTRG
HOLD
NULL
NULL
(5) Corresponding functions for F3-19 is represented by 8-bit binary:
Number
Bit7
Bit6
Bit5
Bit4
Bit3
Bit2
Bit1
Bit0
